Pivot Joint 28 - 1.1" with Locking Lever
Part #: 093GF28A · 2 variants
To make a pivoting connection between two profiles or panels which can be fixed at any angle; fixed locating pins for slot 8 optional; by tightening or loosening the screws and the KIPP-locking lever you can seamlessly regulate the functionality of the joint or you can fix it in one position
Price, availability and delivery time — we send one quote for all products.
Question about this product?
Technical questions, custom versions or quantities — write or call us.
Enquire about this product- Pack
- 10 pieces
- Weight
- 150 g
- ECLASS
- 23360301
- Category
- for Profile 1.1", Pivot Joints
Versions
Select a version — the description and files below follow your selection.
| Part # | Slot N (mm) | Opening Angle | Add 1 pc to enquiry |
|---|---|---|---|
| 093GF28A✓ Selected | - | 190° | |
| 093GF28AN08 | 8 | 190° |
Description 093GF28A
- Color
Alu color
- Description
To make a pivoting connection between two profiles or panels which can be fixed at any angle; fixed locating pins for slot 8 optional; by tightening or loosening the screws and the KIPP-locking lever you can seamlessly regulate the functionality of the joint or you can fix it in one position
- Material
Joint: Zinc die-cast
KIPP-locking lever: Plastic PA, glass fiber reinforced
- Specials
Other surfaces, other colors on request
- Surface
Powder coated
Properties
| Product Feature | Fractional |
|---|---|
| Pack Quantity | 10 pieces |
| Model | Zinc die-cast |
CAD models
FATH's 3D models and drawings are downloaded from their CADENAS PARTcommunity catalogue — free registration, more than 100 formats.
